Size	L	ød	øk	øD	Bolting	øa	Weight
DN 15	130 mm	45 mm	65 mm	95 mm	4 x 14 (M12)	32 mm	3 kg
DN 20	150 mm	58 mm	75 mm	105 mm	4 x 14 (M12)	32 mm	4 kg
DN 25	160 mm	68 mm	85 mm	115 mm	4 x 14 (M12)	48 mm	5.5 kg
DN 40	200 mm	88 mm	110 mm	150 mm	4 x 18 (M16)	65 mm	9.6 kg
DN 50	230 mm	102 mm	125 mm	165 mm	4 x 18 (M16)	80 mm	12.5 kg
DN 80	310 mm	138 mm	160 mm	200 mm	8 x 18 (M16)	100 mm	25.5 kg
DN 100	350 mm	158 mm	180 mm	220 mm	8 x 18 (M16)	125 mm	31.5 kg
DN 150	480 mm	212 mm	240 mm	285 mm	8 x 22 (M20)	142 mm	68 kg
DN 200	600 mm	268 mm	295 mm	340 mm	12 x 22 (M20)	190 mm	88 kg
DN 250	533 mm					220 mm	115 kg

Size	L	ød	øk	øD	Bolting	øa	Weight
NPS ½"	108 mm	34.9 mm	60.3 mm	88.9 mm	4 x 15.9	32 mm	3 kg
NPS ¾"	117 mm	42.9 mm	69.8 mm	98.4 mm	4 x 15.9	32 mm	4 kg
NPS 1"	127 mm	50.8 mm	79.4 mm	108 mm	4 x 15.9	48 mm	4.8 kg
NPS 1½"	165 mm	73 mm	98.4 mm	127 mm	4 x 15.9	65 mm	8.8 kg
NPS 2"	178 mm	92.1 mm	121 mm	152.4 mm	4 x 19	80 mm	11.5 kg
NPS 3"	203 mm	127 mm	152.4 mm	190.5 mm	4 x 19	100 mm	22 kg
NPS 4"	229 mm	157.2 mm	190 mm	228.6 mm	8 x 19	125 mm	28.8 g
NPS 6"	394 mm	216 mm	241 mm	279 mm	8 x 22.2	142 mm	62 kg
NPS 8"	457 mm	269.9 mm	330.2 mm	381 mm	12 x 25.4	190 mm	82 g
NPS_10"	533 mm					220 mm
